Following is our online catalog.
For ordering information, please call, fax, or E-mail
us for details. Suggested retail is shown.
About
Skid Wheels: Pak RV Skid
Wheels are mounted on the rear of the RV. They are necessary
on vehicles which tend to drag while on an incline. Usage of
skid wheels helps prevent damage to equipment that would otherwise
scrape while dragging. They are positioned so that they make
contact first, and are very strong so that they can handle both
impact and weight. There are two main types of skid wheels: frame mount and hitch
bar mount. Frame mounted types are designed to mount
underneath the RV, in a spot on it's frame where they will be
low enough to make contact first, but not too low- so as to drag
unneccesarily. Hitch bar mount skid wheels are to be installed
directly on the hitch bar of a motorhome.
FRAME
MOUNT SKID WHEELS...
   |
| Three sizes of this extra heavy duty model are
available. Each are plate-mount, and include super strong metal
wheels with roller bearings, grease fittings, and 1/4" of
tough urethane on the outer edge. Steel mounting plates and hardware
are included. The four inch model includes cold forged regular
duty steel swivel casters and 4"x 2" wheels. The five
inch model contains large cold forged steel swivel casters and
5"x 2" wheels. The six inch model includes massive
drop forged steel swivel casters and 6"x 2" wheels.
One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
| 10-4218:
4" EHD Skid Whl (pr) |
Small-
medium sized trailers and 5th wheels to 24' in length |
$114.95 |
| 10-4205:
5" EHD Skid Whl (pr) |
Small, medium, and large travel
trailers, 5th wheels and class "C" motorhomes |
$170.85 |
| 10-4208:
6" EHD Skid Whl (pr) |
Largest and heaviest class
"A" motor homes, 5th wheels and travel trailers |
$252.83 |
 |
These
wheels can be used as extra heavy duty replacements for Pak and
any other manufacturer's casters of the same size, as well as
exact replacements for our extra heavy duty line (shown above).
The wheels are metal with roller bearings, grease fittings, and
1/4" of tough urethane on the outer edge. All three sizes
are designed for a 1/2" diameter axle bolt (not included).
Wheels are sold one per display box. One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
| 10-3223:
4" EHD Repl Whl (1) |
Small-
medium sized trailers and 5th wheels to 24' in length |
$28.13 |
| 10-3222:
5" EHD Repl Whl (1) |
Small, medium, and large travel
trailers, 5th wheels and class "C" motorhomes |
$31.03 |
| 10-3221:
6" EHD Repl Whl (1) |
Largest and heaviest class
"A" motorhomes, 5th wheels and travel trailers |
$38.10 |
Top
HITCH
BAR MOUNT SKID WHEELS...
The following products are
designed to mount directly to the hitch bar of a motorhome, and
help prevent damage to the undercarriage and to the hitch. Each
are very easy to install, no drilling or welding is required.
 |
This is
a swivel model and is designed to fit 2-1/2" hitch bars.
The metal wheels are 4"x 2" with roller bearings, grease
fittings, and 1/4" of tough urethane on the outer edge.
One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
|
10-2219: Swivel Hitch Bar
Mount Skid Wheel (pr) |
Any size class "C",
small to medium size class "A" (NO rear engine motorhomes!) |
$99.43 |
 |
This is
a rigid model, and is designed to fit both 2-1/2" and 3-1/2"
hitch bars. The metal wheels are 4"x 2" with roller
bearings, grease fittings, and 1/4" of tough urethane on
the outer edge. One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
|
10-2217: Universal Hitch
Bar Mount Skid Wheel (pr) |
Medium to large motorhomes
(NO rear engine motorhomes!) |
$101.18 |
 MORE INFORMATION |
This model
is the strongest available. There are two offered: one to fit
a 2-1/2" square hitch bar, and one to fit a 3"square
hitch bar. The solid steel wheels have roller bearings
and grease fittings on the bolt for easy lubrication. For detailed
specifications on this product and information on the accessory
package, please see HITCH
ROLLER INFO. Wheels are also sold separately for replacement
purposes. Made in USA. One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
| 10-4217:
Solid Steel Hitch Rollers (pr) {2-1/2" model} |
Largest
and heaviest motorhomes, including rear engine types |
$151.23 |
| 10-4217-3: Solid Steel Hitch Rollers (pr) {3"
model} |
Largest and heaviest motorhomes,
including rear engine types |
$151.23 |
| 10-3224:
Solid Steel Replacement Roller (1) |
Largest and heaviest motorhomes,
including rear engine types |
$49.33 |
Top
SKID BAR MOUNT SKID
WHEELS...
 |
This model
bolts onto RV's skid bars. Fits skid bars up to 2" wide
(skid bars NOT included!). Wheel size is 3"x 1-1/4"
and made of polyolefin material. Mounting hardware is included.
Replacement wheels are available. Made in USA. One year
warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
| 10-2201:
Bolt- On Skid Wheels (pr) |
Lightweight
trailers and RV's only. |
$33.08 |
| 10-2210:
Replacement Wheels (pr) |
Lightweight trailers and RV's
only. |
$7.43 |
Top
SOLID STEEL HITCH PROTECTOR
SKID WHEEL...
 |
This item
protects the receiver and hitch post from road damage. It can
be used with or without trailer. Receiver and hitch pin are NOT
included. Contains an extra heavy duty, 2-1/2"x 1-1/2"
solid billet steel wheel. For older models which had plastic
wheels, there is a replacement wheel/ upgrade kit available containing
the steel wheel, heavy duty axle bolt, washers and lock nut.
Made in USA. One year warranty. |
|
Stock#/ Description |
Recommended Usage |
Suggested Retail |
| 10-4216:
Steel Hitch Protector (1) |
Vehicles
of any size, including the largest and heaviest RV's.. |
$36.23 |
| 10-4214:
Repl Whl/Upgrade Kit (1) |
Vehicles of any size, including
the largest and heaviest RV's. |
$19.63 |
